Integrated echocardiographic imaging of giant atrial myxoma

Integrated echocardiographic imaging of giant atrial myxoma



Roberto Cemin1*, Renato Di Gaetano1, Giovanni Battista Luciani2 and Andrea Erlicher11Department of Cardiology, Bolzano General Hospital, Bolzano, Italy

2Division of Cardiac Surgery, University of Verona, Verona, Italy



Journal of Cardiovascular Diseases & Diagnosis



A 50-year-old woman with a history of pituitary adenoma underwent transthoracic echocardiography (TTE) to assess cardiac valve function after previous treatment with cabergoline. TTE ruled out valve pathology, but showed a large rounded mass within the left atrium (Figure 1). The mass adhered to the interatrial septum and projected toward the mitral valve during ventricular diastole without generating flow obstruction. The findings were suggestive of left atrial myxoma. In order to evaluate vascularisation of the mass, contrast echocardiography was performed using a second-generation contrast agent (SonoVue® Bracco Imaging, Milan, Italy) with real time perfusion imaging. The slow contrast refilling of the mass after a high-energy ultrasound pulse was suggestive of low vascularisation (Figure 1), typical of benign tumors [1].



Transesophageal chocardiography (TEE) was performed to further characterize morphology, volume and site of adhesion of the mass and to aide planning [2]. 2D TEE confirmed diagnosis of giant left atrial mass and attachment to the atrial septum. The real-time 3D (RT-3D) TEE allowed to display a virtual atriotomic view, familiar and valuable to the surgeon. Particularly useful was the assessment of the very broad adhesion of the mass, which was unusually located on the atrial septum and roof of the left atrium (Figure 2). Radical excision was performed using a biatrial approach. Firstly, via right atriotomy, the septum primum was incised circumferentially to mobilize the septal adhesion of the mass. Secondly, via left atriotomy, the insertion onto the roof of the left atrium was excised along with a patch of left atrial free wall. Histology was compatible with myxoma. The wall defect was repaired primarily, while the atrial septal defect was patched with autologous pericardium.



Cardiac tumor; 3D echocardiography; Contrast echocardiography


© 2017 Cemin R, et al. This is an open-access article distributed under the terms of the Creative Commons Attribution License, which permits unrestricted use, distribution, and reproduction in any medium, provided the original author and source are credited.



Kirkpatrick JN, Wong T, Bednarz JE, Spencer KT, Sugeng L, et al. (2004) Differential diagnosis of cardiac masses using contrast echocardiographic perfusion imaging. J Am Coll Cardiol43: 1412–1419.
Scohy TV, Lecomte PV, Mc Ghie J (2008) Intraoperative real time three-dimensional transesophageal echocardiographic evaluation of right atrial tumor. Echocardiography 25: 646–649.
